Accel FX Power Source 8 power supply (isolated outputs) for guitar effects and loop switchers.

FX PowerSource 8 Guitar Pedal Power Supply (Isolated Outputs)

Accel
SKU:
PS-8-1-DO
|
UPC:
881314740536
Availability:
Usually ships in 1-2 business days.
$189.00
$220.00
(You save $31.00 )
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Accel "FX Power Source 8" Eight Output Power Supply: Designed with a high efficiency transformer. Each output is fully isolated, regulated and filtered with over voltage protection.
Equipped with a voltage select switch, allowing this power supply to work properly anywhere in the world.
The all-aluminum anodized enclosure dissipates the heat rapidly and keeps components cool.

The "FX Power Source 8"" mounts easily and conveniently to all FX and XTA series pedal boards with only three (supplied) M4 mounting screws.

The Power Source 8, powers 9V, 12V & 18V effects pedals. While there are 2 adjustable outputs (9V-18V & 5V-9V) and 4 selectable outputs (9V or 12V), 9V’s is available on all outputs to work with the majority of the pedals on the market.

What's Included
• Accel FX Power Source 8 Power Supply
• (1) AC Input cord
• (2) 7.9” [20cm] Line 6 Converter Cables
• (2) 19.7” [50 cm] Negative Center Output Cables
• (6) 27.5” [70 cm] Negative Center Output Cables
• (1) Power Supply Mounting Template
• (3) M4 x 8 mm Mounting Screws
• User's Manual

Features:
• All Outputs Isolated, Filtered with Overvoltage Protection
• Selectable input (100 -240V)
• 1 Auxiliary AC output
• Transformer based design with separate grounds for true isolation!
• Adjustable and selectable output voltages 5V -18V. 9Volts are available on all 8 DC outputs
• 3 customer threaded mounting power supply mounting holes with supplied mounting screws

Specs:
· AC Input (Selectable): 100V to 240V.
· AC Output (Auxiliary): 150W
· DC Output 1: Adjustable: 9V@ 50mA - 18V@25mA
· DC Output 2: Adjustable:· 5V@ 180mA - 9V@100mA
· DC Outputs 3-6: Selectable: 9V@ 100mA - 12V@60mA
· DC Output 7: 9V@ 350mA
· DC Output 8: 9V@ 350mA
· Dimensions: 6.00” (152mm) W x 3.50” (89mm) DP x 1.75” (44mm) H
· Weight 1 lb 9oz
